Item # bci2844128

Copper Creek Mid Century Modern Passage Door Lever Set with Verona Lever and Square Rose

Model: VL2220PS

from the Mid Century Modern Collection
$34.00
Finish: Choose Finish
  • Polished Stainless
  • Satin Stainless
  • Tuscan Bronze
  • Polished Stainless
    Polished Stainless
    $34.00
    500 In Stock
  • Satin Stainless
    Satin Stainless
    $31.65
    500 In Stock
  • Tuscan Bronze
    Tuscan Bronze
    $32.50
    209 In Stock

Function: Passage

Passage
PrivacySingle Dummy

Free Shipping on orders over $49.00!

500 In Stock
Configure Your Copper Creek VL2220 Mid Century Modern Passage Door Lever Set with Verona Lever and Square Rose

  • Latch Type

    Most residential doors are mortised for either a round corner or square corner latch. Drive-in latches do not have a faceplate and are generally used on hollow doors.
    Please Select One
$34.00

Product Overview

passage-functionPassage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn't needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.

Features:

  • Exceeds criteria for BHMA Grade 3 certification
  • Durable construction and high attention to detail
  • Premium finish maintains its appearance over time
  • Designed for both left and right hand door configurations
  • Includes square corner, round corner, or drive-in latch faceplate
  • Complies with standards of the Americans with Disabilities Act (ADA)
  • Covered under Limited Lifetime Mechanical and 5 Year Finish Warranty

Specifications:

  • Backset: Adjustable 2-3/8" or 2-3/4"
  • Cross Bore: 2-1/8"
  • Edge Bore: 1"
  • Door Thickness: 1-3/8" to 1-3/4"
  • Handing: Reversible Left or Right
  • Trim Height: 2-5/8"
  • Trim Width: 2-5/8"
  • Handle Length: 4-1/4"
  • Handle Projection: 2-1/4"
  • Latch Faceplate: Round Corner, Square Corner or Drive-In
  • Material: Brass, Steel, Zinc
Product Variations:
  • VL2290: Single Dummy Door Lever
  • VL2220 (This Model): Passage Door Lever Set
  • VL2231: Privacy Door Lever Set

This product is listed under the following manufacturer number(s):

Dimensions and Measurements

Backset
2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4"
Cross Bore
2-1/8"
Door Thickness
1-1/2", 1-3/4", 1-3/8", 1-5/8"
Edge Bore
1"
Handle Height
2.5 in.
Handle Length
4.25 in.
Handle Projection
2.25 in.
Handle Width
2.5 in.
Trim Height
2.625 in.
Trim Width
2.625 in.

Included Components

28 Degree Latch
No

Characteristics and Features

Concealed Screws
Yes
Function
Passage
Handing
Left, Reversible, Right
Handle Design
Verona
Handle Material
Metal
Interconnected
No
Latch Faceplate
Drive-In, Square Corner, Round Corner
Lever Shape
Square, Straight
Material
Brass, Steel, Zinc
Panic Proof
No
Removable Core
No
Rosette Shape
Square
Theme
Transitional

Manufacturer Technology

SmartKey
No

Warranty and Product Information

ADA
Yes
ANSI Certification
A156.2
Approved for Commercial Use
No
BHMA Certification
Grade 3
Certifications
ANSI, UL
Collection
Mid Century Modern
Country Of Origin
Taiwan
Fire Rated
No
Manufacturer Warranty
Limited Lifetime Mechanical, 5 Year Finish
Series
Verona
